CASE PSU ATX 1000W/PPG-1000-C CHIEFTEC

CASE PSU ATX 1000W/PPG-1000-C CHIEFTEC
CASE PSU ATX 1000W/PPG-1000-C CHIEFTEC
  • Total power: 1000
  • 80 PLUS certification: 80 PLUS Gold
  • Power supply unit (PSU) form factor: ATX
  • Fan diameter: 135
    • Врз основа на 0 коментари. - Напиши коментар
    7,892ден.
    • Достапност: Има залиха
    • Шифра: 453261
    • Гарантен рок: 12 месеци
    • Рок на испорака: 22.03
    CHIEFTEC
    Во кошничка
    Листа на желби Спореди
    Сподели

    Technical Specifications

    • Summary: Chieftec Vega PPG-1000-C. Total power: 1000 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 24-pin ATX, Motherboard power cable length: 60 cm, SATA power cable length: 150,400 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: White, Cooling type: Active, Fan diameter: 13.5 cm. Certification: 80PLUS Gold
    • Name: CASE PSU ATX 1000W/PPG-1000-C CHIEFTEC
    • Category Code: PSU
    • Total power: 1000
    • AC input voltage: 100 - 240
    • AC input frequency: 50/60
    • Input current: 12
    • Combined power (+3.3V): 100
    • Combined power (+12V): 1000
    • Combined power (+5V): 100
    • Combined power (-12V): 3.6
    • Combined power (+5Vsb): 15
    • Max output current (+3.3V): 20
    • Max output current (+12V): 83.33
    • Max output current (+5V): 20
    • Max output current (-12V): 0.3
    • Max output current (+5Vsb): 3
    • Power protection features: Over current/Over voltage/Overload/Short circuit/Surge and inrush
    • Motherboard power connector: 24-pin ATX
    • Motherboard power cable length: 600
    • Number of SATA power connectors: 6
    • SATA power cable length: 150/400
    • Peripheral (Molex) power connectors (4-pin): 3
    • Peripheral (Molex) power cable length: 150/400
    • EPS power connector (8-pin): Yes
    • EPS power connector (4+4 pin): Yes
    • PCI Express power connectors (6+2 pin): 4
    • PCI Express power connectors (12+4 pin): 1
    • PCI Express power connectors (12+4 pin) cable length: 600
    • PCI Express power cable length: 600
    • CPU power connector (4+4 pin): Yes
    • CPU power cable length: 650
    • ATX Power connector (24-pin): Yes
    • Number of EPS connectors: 2
    • PCI Express connector: Yes
    • Cabling type: Fully-Modular
    • 80 PLUS certification: 80 PLUS Gold
    • Purpose: PC
    • Power supply unit (PSU) form factor: ATX
    • ATX version: 3.1
    • Bearing technology: FDB
    • Product colour: White
    • Cooling type: Active
    • Fan diameter: 135
    • Certification: 80PLUS Gold
    • Width: 150
    • Depth: 150
    • Height: 85
    • Units per Pallet: 0
    • Units per Shipping Box: 1
    • Unit Calculated Volume: 0.006468
    • Unit Calculated Weight: 3.5
