CASE PSU ATX 850W/PPS-850FC-A3 CHIEFTEC

CASE PSU ATX 850W/PPS-850FC-A3 CHIEFTEC
Нема на залиха
CASE PSU ATX 850W/PPS-850FC-A3 CHIEFTEC
  • Total power: 850
  • 80 PLUS certification: 80 PLUS Gold
  • Power supply unit (PSU) form factor: ATX
  • Fan diameter: 135
    • Врз основа на 0 коментари. - Напиши коментар
    10,529ден.
    • Достапност: Нема на залиха
    • Бренд: CHIEFTEC
    • Шифра: 404089
    • Гарантен рок: 12 месеци
    • Достава: 13-16 дена
    Во кошничка
    Листа на желби Спореди
    1

    Technical Specifications

    • Summary: Chieftec Polaris 3.0 850W. Total power: 850 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 65 cm, SATA power cable length: 100,550 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 13.5 cm. Compliance certificates: RoHS, Federal Communications Commission (FCC), EAC, CB, CE
    • Vendor Homepage: https://www.chieftec.eu/products-detail/544/POLARIS_3.0_SERIES_/545/PPS-850FC-A3
    • Name: CASE PSU ATX 850W/PPS-850FC-A3 CHIEFTEC
    • Category Code: PSU
    • Total power: 850
    • AC input voltage: 100 - 240
    • AC input frequency: 50/60
    • Input current: 12-8
    • Power factor: 0.9
    • Power Factor Correction (PFC) type: Active
    • Combined power (+3.3V): 120
    • Combined power (+5V): 120
    • Combined power (-12V): 3.6
    • Combined power (+5Vsb): 15
    • Max output current (+3.3V): 22
    • Max output current (+12V1): 70.8
    • Max output current (+5V): 22
    • Max output current (-12V): 0.3
    • Max output current (+5Vsb): 3
    • Power protection features: Over current/Over voltage/Overload/Short circuit/Under voltage
    • Motherboard power connector: 20+4 pin ATX
    • Motherboard power cable length: 650
    • Number of SATA power connectors: 12
    • SATA power cable length: 100/550
    • Peripheral (Molex) power connectors (4-pin): 4
    • Peripheral (Molex) power cable length: 100/550
    • EPS power connector (8-pin): Yes
    • PCI Express power connectors (6+2 pin): 2
    • PCI Express power connectors (16-pin): 1
    • Cabling type: Fully-Modular
    • 80 PLUS certification: 80 PLUS Gold
    • Purpose: PC
    • Power supply unit (PSU) form factor: ATX
    • ATX version: 3.0
    • Bearing technology: FDB
    • Product colour: Black
    • Cooling type: Active
    • Fan diameter: 135
    • Compliance certificates: CB/CE/EAC/Federal Communications Commission (FCC)/RoHS
    • Width: 150
    • Depth: 160
    • Height: 86
    • Weight: 2890
    • Package weight: 3240
    • Package type: Box
    • Sustainability compliance: Yes
    • Warranty period: 5
    • Model name: PPS-850FC-A3
    • Units per Shipping Box: 1
    • Unit Calculated Volume: 0.003927
    • Unit Calculated Weight: 3.5
    Specs
    80 PLUS certification 80 PLUS Gold
    AC input frequency 50/60
    AC input voltage 100 - 240
    ATX version 3.0
    Bearing technology FDB
    Cabling type Fully-Modular
    Category Code PSU
    Combined power (+3.3V) 120
    Combined power (+5V) 120
    Combined power (+5Vsb) 15
    Combined power (-12V) 3.6
    Compliance certificates CB/CE/EAC/Federal Communications Commission (FCC)/RoHS
    Cooling type Active
    Depth 160
    Description

    The CHIEFTEC Polaris 3.0 series is designed to Intel’s ATX 3.0 standard and supports PCIe GEN 5 with 80 PLUS® GOLD certified efficiency, promising exceptional performance. Polaris 3.0 features state-of-the-art technical design including LLC half-bridge converter with DC- to-DC technology, as well as Japanese main capacitors to achieve low ripple and tight voltage regulation. The Polaris 3.0 135mm FDB silent fan optimizes the balance between cooling and noise with excellent durability. Fully modular cable management ensures a clean and convenient build inside any system.

    • ATX 3.0 with PCIe GEN5
    • 80PLUS® GOLD certified efficiency
    • Japanese Main Capacitors
    • LLC Half-Bridge converter with DC to DC technology
    • Fully modular cable management
    EPS power connector (8-pin) Yes
    Fan diameter 135
    Height 86
    Input current 12-8
    Max output current (+12V1) 70.8
    Max output current (+3.3V) 22
    Max output current (+5V) 22
    Max output current (+5Vsb) 3
    Max output current (-12V) 0.3
    Model name PPS-850FC-A3
    Motherboard power cable length 650
    Motherboard power connector 20+4 pin ATX
    Name CASE PSU ATX 850W/PPS-850FC-A3 CHIEFTEC
    Number of SATA power connectors 12
    Package type Box
    Package weight 3240
    PCI Express power connectors (16-pin) 1
    PCI Express power connectors (6+2 pin) 2
    Peripheral (Molex) power cable length 100/550
    Peripheral (Molex) power connectors (4-pin) 4
    PictureUrl https://static.elko.cloud/ProductImages/7a02f0bf-25a3-4892-9978-f1ef7e4c8586.Jpeg
    Power factor 0.9
    Power Factor Correction (PFC) type Active
    Power protection features Over current/Over voltage/Overload/Short circuit/Under voltage
    Power supply unit (PSU) form factor ATX
    Product colour Black
    Purpose PC
    SATA power cable length 100/550
    Summary Chieftec Polaris 3.0 850W. Total power: 850 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 65 cm, SATA power cable length: 100,550 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 13.5 cm. Compliance certificates: RoHS, Federal Communications Commission (FCC), EAC, CB, CE
    Sustainability compliance Yes
    thumbnailImagePath https://static.elko.cloud/ProductImagesThumbs/7a02f0bf-25a3-4892-9978-f1ef7e4c8586.Jpeg
    Total power 850
    Unit Calculated Volume 0.003927
    Unit Calculated Weight 3.5
    Units per Shipping Box 1
    Vendor Homepage https://www.chieftec.eu/products-detail/544/POLARIS_3.0_SERIES_/545/PPS-850FC-A3
    Warranty period 5
    Weight 2890
    Width 150
