CPU CORE U5-250K PLUS BOX/3.3G BX80768250K S A4UZ IN

Technical Specifications

• Summary: Intel Core Ultra 5 250K Plus. Processor family: Intel Core Ultra 5, Processor socket: FCLGA1851, Package type: Box. Neural processor unit (NPU): Intel AI Boost, AI software frameworks supported by NPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN, Total processor performance up to: 30 TOPs. Memory channels: Dual-channel, Maximum internal memory supported by processor: 256 GB, Memory types supported by processor: DDR5-SDRAM. On-board graphics card model: Intel® Graphics, On-board graphics card base frequency: 300 MHz, On-board graphics card dynamic frequency (max): 1900 MHz. Market segment: Desktop, Use conditions: Workstation, PC/Client/Tablet, PCI Express slots version: 4.0, 5.0
• Vendor Homepage: https://www.intel.com/content/www/us/en/products/sku/245694/intel-core-ultra-5-processor-250k-plus-30m-cache-up-to-5-30-ghz/ordering.html
• Name: CPU CORE U5-250K PLUS BOX/3.3G BX80768250K S A4UZ IN
• Category Code: CPU
• Processor manufacturer: Intel
• Processor generation: Intel Core Ultra (Series 2)
• Processor model: 250K Plus
• Processor family: Intel Core Ultra 5
• Processor cores: 18
• Processor socket: FCLGA1851
• Processor threads: 18
• Processor operating modes: 64-bit
• Performance cores: 6
• Efficient cores: 12
• Processor boost frequency: 5.3
• Performance-core boost frequency: 5.3
• Performance-core base frequency: 4.2
• Efficient-core boost frequency: 4.6
• Efficient-core base frequency: 3.3
• Processor cache: 30
• Processor cache type: Smart Cache
• Package type: Box
• Maximum turbo power: 159
• Processor base power: 125
• AI software frameworks supported by CPU: DirectML/ONNX RT/OpenVINO/WebNN/Windows ML
• Maximum number of DMI lanes: 8
• Processor codename: Arrow Lake
• Processor ARK ID: 245694
• Neural processor unit (NPU): Intel AI Boost
• Sparsity support: Yes
• Windows Studio effects support: Yes
• AI software frameworks supported by NPU: DirectML/ONNX RT/OpenVINO/WebNN/Windows ML
• Total processor performance up to: 30
• NPU performance up to: 13
• GPU performance up to: 8
• Maximum internal memory supported by processor: 256
• Memory types supported by processor: DDR5-SDRAM
• Memory channels: Dual-channel
• ECC: Yes
• On-board graphics card: Yes
• On-board graphics card model: Intel Graphics
• On-board graphics card base frequency: 300
• On-board graphics card dynamic frequency (max): 1900
• Number of displays supported (on-board graphics): 4
• On-board graphics card DirectX version: 12.0
• On-board graphics card OpenGL version: 4.5
• On-board graphics card maximum resolution (DisplayPort): 7680 x 4320
• On-board graphics card refresh rate at maximum resolution (DisplayPort): 60
• On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel): 120
• On-board graphics card refresh rate at maximum resolution (HDMI): 60
• On-board graphics card ID: 0x7D67
• Hardware encode/decode codecs supported: H.264/H.265 (HEVC)
• AI software frameworks supported by GPU: DirectML/ONNX RT/OpenVINO/WebGPU/Windows ML
• AV1 encode/decode: Yes
• Xe-cores: 4
• Execute Disable Bit: Yes
• Idle States: Yes
• Thermal Monitoring Technologies: Yes
• Market segment: Desktop
• Use conditions: PC/Client/Tablet/Workstation
• Maximum number of PCI Express lanes: 24
• PCI Express slots version: 4.0/5.0
• Supported instruction sets: AVX 2.0/SSE4.1/SSE4.2
• Direct Media Interface (DMI) Revision: 4.0
• Scalability: 1S
• Thermal solution specification: PCG 2020A
• Enhanced Intel SpeedStep Technology: Yes
• Intel Trusted Execution Technology: Yes
• Intel AES New Instructions (Intel AES-NI): Yes
• Intel Quick Sync Video Technology: Yes
• Intel Speed Shift Technology: Yes
• Intel Turbo Boost Technology: 2.0
• Intel Thunderbolt 4: Yes
• Intel Control-flow Enforcement Technology (CET): Yes
• Intel Thread Director: Yes
• Intel 64: Yes
• Intel Virtualization Technology (VT-x): Yes
• Intel Virtualization Technology for Directed I/O (VT-d): Yes
• Intel VT-x with Extended Page Tables (EPT): Yes
• Intel Active Management Technology (Intel AMT): Yes
• Intel Boot Guard: Yes
• Intel Deep Learning Boost (Intel DL Boost) on CPU: Yes
• Intel Deep Learning Boost (Intel DL Boost) on GPU: Yes
• Intel One-Click Recovery: Yes
• Intel OS Guard: Yes
• Intel Remote Platform Erase (RPE): Yes
• Intel Secure Key: Yes
• Intel Stable IT Platform Program (SIPP): Yes
• Intel Standard Manageability (ISM): Yes
• Intel Virtualization Technology with Redirect Protection (VT-rp): Yes
• Intel Volume Management Device (VMD): Yes
• Intel vPro Platform Eligibility: Yes
• Mode-based Execute Control (MBE): Yes
• Intel vPro Enterprise Platform Eligibility: Yes
• Intel Threat Detection Technology (TDT): Yes
• Intel Total Memory Encryption - Multi Key: Yes
• Maximum operating temperature: 105
• OpenCL version: 3.0
• Launch date: Q126
• Status: Launched
• Processor package size: 45 x 37.5
• Graphics output: eDP1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL
• L2 cache: 30720
• Maximum internal memory: 256
• Units per Pallet: 0
• Units per Shipping Box: 5
• Unit Calculated Volume: 0.00072
• Unit Calculated Weight: 0.106
