  • Motherboard chipset: Intel B760
  • Motherboard form factor: micro ATX
  • Processor socket: LGA 1700
  • Supported memory types: DDR4-SDRAM
  • Number of memory slots: 2
  • Number of storage drives supported: 6
    • Врз основа на 0 коментари. - Напиши коментар
    8,415ден.
    • Достапност: Има залиха
    • Бренд: ASUS
    • Шифра: 394183
    • Гарантен рок: 36 месеци
    • Достава: 13-16 дена
    Во кошничка
    Листа на желби Спореди
    1
    Specifications
    ECC сompatibilityNon-ECC
    Unit Depth27
    Unit Height5
    Unit Width27
    Specs
    12V power connectorYes
    ATX Power connector (24-pin)Yes
    Audio output channels7.1
    BIOS memory size128
    BIOS typeUEFI AMI
    Cables includedSATA
    Category CodeMBI
    Compatible processor seriesIntel® Celeron®/Intel® Core™ i3/Intel® Core™ i5/Intel® Core™ i7/Intel® Core™ i9/Intel® Pentium® Gold
    Component forPC
    CPU fan connectorYes
    Depth211
    EPS power connector (8-pin)Yes
    Ethernet interface type2.5 Gigabit Ethernet
    Ethernet LANYes
    Ethernet LAN (RJ-45) ports1
    Front panel audio connectorYes
    HDMI ports quantity1
    Height36
    Maximum internal memory64
    Memory channelsDual-channel
    Memory slots typeDIMM
    Microphone inYes
    ModelPRIME B760M-K D4
    Motherboard chipsetIntel B760
    Motherboard chipset familyIntel
    Motherboard form factormicro ATX
    NameMB B760 S1700 MATX/PRIME B760M-K D4 ASUS
    Number of chassis fan connectors1
    Number of COM connectors1
    Number of HDDs supported4
    Number of M.2 (M) slots2
    Number of memory slots2
    Number of SATA III connectors4
    Number of storage drives supported6
    Package depth51.5
    Package height263
    Package weight926.3
    Package width270
    Parallel processing technology supportNot supported
    PCI Express x1 (Gen 4.x) slots2
    PCI Express x16 (Gen 4.x) slots1
    Processor manufacturerIntel
    Processor socketLGA 1700
    Product Net Weight0.7
    Product typeOffice
    PS/2 ports quantity1
    RAID levels0/1/10/5
    RAID supportYes
    RGB LED pin headerYes
    S/PDIF out connectorYes
    Shipping Box Depth27
    Shipping Box Height5
    Shipping Box Weight1
    Shipping Box Width27
    SummaryASUS PRIME B760M-K D4. Processor manufacturer: Intel, Processor socket: LGA 1700, Compatible processor series: Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9,.... Supported memory types: DDR4-SDRAM, Maximum internal memory: 64 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. USB connector type: USB Type-A. Ethernet interface type: 2.5 Gigabit Ethernet
    Supported memory clock speed (max)5333
    Supported memory clock speeds2133/2400/2666/2800/2933/3000/3200/3333/3400/3466/3600/3733/4000/4266/4400/4600/4800/5000/5066/5333
    Supported memory typesDDR4-SDRAM
    Supported processor socketsLGA 1700
    Supported storage drive interfacesM.2,SATA III
    Supported storage drive typesHDD & SSD
    TPM connectorYes
    Unbuffered memoryYes
    Unit Calculated Volume0.003645
    Unit Calculated Weight1
    Units per Shipping Box1
    USB 2.0 connectors2
    USB 2.0 ports quantity2
    USB 3.2 Gen 1 (3.1 Gen 1) connectors1
    USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
    USB connector typeUSB Type-A
    Vendor Homepagewww.asus.com/motherboards-components/motherboards/prime/prime-b760m-k-d4/
    VGA (D-Sub) ports quantity1
    Wake-on-LAN readyYes
    Weight528
    Width244
    Windows operating systems supportedWindows 10 x64/Windows 11
