H610M S2H V2

H610M S2H V2
H610M S2H V2
  • Motherboard chipset: Intel H610 Express
  • Motherboard form factor: micro ATX
  • Processor socket: LGA 1700
  • Supported memory types: DDR5-SDRAM
  • Number of memory slots: 2
  • Number of storage drives supported: 1
    • Врз основа на 0 коментари. - Напиши коментар
    4,572ден.
    • Достапност: Има залиха
    • Бренд: GIGABYTE
    • Шифра: 412701
    • Гарантен рок: 12 месеци
    • Достава: 13-16 дена
    Во кошничка
    Листа на желби Спореди
    1

    Technical Specifications

    • Summary: GIGABYTE H610M S2H V2 Motherboard - Supports Intel Core 14th CPUs, 4+1+1 Hybrid Phases Digital VRM, up to 5600MHz DDR5, 1xPCIe 3.0 M.2, GbE LAN, USB 3.2 Gen 1. Processor manufacturer: Intel, Processor socket: LGA 1700, Compatible processor series: Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9,.... Supported memory types: DDR5-SDRAM, Maximum internal memory: 96 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA, Supported storage drive types: HDD & SSD. Graphics card family: Intel, Graphics card: HD Graphics, Maximum resolution: 4096 x 2304 pixels. Ethernet interface type: Gigabit Ethernet
    • Vendor Homepage: https://www.gigabyte.com
    • Name: MB H610 S1700 MATX/H610M S2H V2 1.0 GIGABYTE
    • Category Code: MBI
    • Model: H610M S2H V2
    • Motherboard chipset: Intel H610 Express
    • Audio chip: Realtek ALC897
    • Product colour: Black
    • PC health monitoring: Fan/LED/Temperature/Voltage/Water cooling
    • Component for: PC
    • Motherboard form factor: micro ATX
    • Audio output channels: 7.1
    • Cooling type: Active
    • Motherboard chipset family: Intel
    • Power source type: ATX
    • Windows operating systems supported: Windows 10 x64/Windows 11 x64
    • Processor manufacturer: Intel
    • Processor socket: LGA 1700
    • Compatible processor series: Intel Celeron/Intel Core i3/Intel Core i5/Intel Core i7/Intel Core i9/Intel Pentium Gold
    • Maximum number of SMP processors: 1
    • Supported processor sockets: LGA 1700
    • Maximum internal memory supported by processor: 96
    • Supported memory types: DDR5-SDRAM
    • Number of memory slots: 2
    • Memory slots type: DIMM
    • Memory channels: Dual-channel
    • ECC сompatibility: ECC & Non-ECC
    • Supported memory clock speeds: 4400/4800/5200/5600
    • Supported memory clock speed (max): 5600
    • Maximum internal memory: 96
    • Supported memory module capacities: 12GB/1GB/2GB/32GB/48GB/4GB/8GB
    • Unbuffered memory: Yes
    • Supported storage drive types: HDD & SSD
    • Supported storage drive interfaces: M.2,SATA
    • Number of HDDs supported: 4
    • Number of storage drives supported: 1
    • On-board graphics card: Yes
    • Graphics card family: Intel
    • Graphics card: HD Graphics
    • Maximum resolution: 4096 x 2304
    • HDCP: Yes
    • On-board graphics card model: Intel HD Graphics
    • USB 2.0 connectors: 2
    • USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
    • Number of SATA III connectors: 4
    • Front panel audio connector: Yes
    • Front panel connector: Yes
    • ATX Power connector (24-pin): Yes
    • CPU fan connector: Yes
    • Number of chassis fan connectors: 2
    • EPS power connector (8-pin): Yes
    • 12V power connector: Yes
    • Number of COM connectors: 1
    • Serial port headers: 1
    • TPM connector: Yes
    • RGB LED pin header: Yes
    • USB 2.0 ports quantity: 4
    • USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
    • Ethernet LAN (RJ-45) ports: 1
    • PS/2 ports quantity: 1
    • VGA (D-Sub) ports quantity: 1
    • HDMI ports quantity: 1
    • DVI-D ports quantity: 1
    • DisplayPorts quantity: 1
    • Headphone outputs: 1
    • Microphone in: Yes
    • Ethernet LAN: Yes
    • Ethernet interface type: Gigabit Ethernet
    • PCI Express x1 slots: 1
    • PCI Express x16 slots: 1
    • Number of M.2 (M) slots: 1
    • BIOS type: UEFI AMI
    • BIOS memory size: 128
    • ACPI version: 5.0
    • Clear CMOS jumper: Yes
    • Clear CMOS button: Yes
    • Desktop Management Interface (DMI) version: 2.7
    • System Management BIOS (SMBIOS) version: 2.7
    • Country of origin: China
    • Products per shipping (inner) case: 1
    • Battery weight: 3
    • Lithium weight per battery: 0.07
    • Package width: 265
    • Number of battery cells: 1
    • Package depth: 235
    • Package height: 52
    • Battery technology: Lithium-Manganese Dioxide (LiMnO2)
    • Package weight: 690
    • Battery type: CR2032
    • Width: 230
    • Depth: 215
    • Height: 35
    • Batteries included: Yes
    • Cables included: SATA
    • Bundled software: Norton Internet Security (OEM version) LAN bandwidth management software
    • Supported DIMM module capacities: 16GB/8GB
    • Warranty period: 3
    • Units per Shipping Box: 10
    • Unit Calculated Volume: 0.004113
    • Unit Calculated Weight: 0.787
    Specs
    12V power connector Yes
    ACPI version 5.0
    ATX Power connector (24-pin) Yes
    Audio chip Realtek ALC897
    Audio output channels 7.1
    Batteries included Yes
    Battery technology Lithium-Manganese Dioxide (LiMnO2)
    Battery type CR2032
    Battery weight 3
    BIOS memory size 128
    BIOS type UEFI AMI
    Bundled software Norton® Internet Security (OEM version) LAN bandwidth management software
    Cables included SATA
    Category Code MBI
    Clear CMOS button Yes
    Clear CMOS jumper Yes
    Compatible processor series Intel® Celeron®/Intel® Core™ i3/Intel® Core™ i5/Intel® Core™ i7/Intel® Core™ i9/Intel® Pentium® Gold
    Component for PC
    Cooling type Active
    Country of origin China
    CPU fan connector Yes
    Depth 215
    Description

    Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge

    • Supports Intel® Coreâ„¢ 14th/ 13th /12th processors
    • Dual Channel Non-ECC Unbuffered DDR5, 2 DIMMs
    • 4+1+1 Hybrid Digital VRM Design
    • GbE LAN with Bandwidth Management
    • NVMe PCIe 3.0 x4 M.2
    • 2*DisplayPort / HDMI / D-Sub Ports for Multiple Display
    • High Quality Audio Capacitors and Audio Noise Guard
    • Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
    • GIGABYTE APP Center, Simple and Easy Use
    • Anti-Sulfur Resistors Design
    Desktop Management Interface (DMI) version 2.7
    DisplayPorts quantity 1
    DVI-D ports quantity 1
    ECC сompatibility ECC & Non-ECC
    EPS power connector (8-pin) Yes
    Ethernet interface type Gigabit Ethernet
    Ethernet LAN Yes
    Ethernet LAN (RJ-45) ports 1
    Front panel audio connector Yes
    Front panel connector Yes
    Graphics card HD Graphics
    Graphics card family Intel
    HDCP Yes
    HDMI ports quantity 1
    Headphone outputs 1
    Height 35
    Lithium weight per battery 0.07
    Maximum internal memory 96
    Maximum internal memory supported by processor 96
    Maximum number of SMP processors 1
    Maximum resolution 4096 x 2304
    Memory channels Dual-channel
    Memory slots type DIMM
    Microphone in Yes
    Model H610M S2H V2
    Motherboard chipset Intel H610 Express
    Motherboard chipset family Intel
    Motherboard form factor micro ATX
    Name MB H610 S1700 MATX/H610M S2H V2 1.0 GIGABYTE
    Number of battery cells 1
    Number of chassis fan connectors 2
    Number of COM connectors 1
    Number of HDDs supported 4
    Number of M.2 (M) slots 1
    Number of memory slots 2
    Number of SATA III connectors 4
    Number of storage drives supported 1
    On-board graphics card Yes
    On-board graphics card model Intel® HD Graphics
    Package depth 235
    Package height 52
    Package weight 690
    Package width 265
    PC health monitoring Fan/LED/Temperature/Voltage/Water cooling
    PCI Express x1 slots 1
    PCI Express x16 slots 1
    PictureUrl https://static.elko.cloud/ProductImages/369ac597-61dd-47d4-b4fe-bbb337e77806.Jpeg
    Power source type ATX
    Processor manufacturer Intel
    Processor socket LGA 1700
    Product colour Black
    Products per shipping (inner) case 1
    PS/2 ports quantity 1
    RGB LED pin header Yes
    Serial port headers 1
    Summary GIGABYTE H610M S2H V2 Motherboard - Supports Intel Core 14th CPUs, 4+1+1 Hybrid Phases Digital VRM, up to 5600MHz DDR5, 1xPCIe 3.0 M.2, GbE LAN, USB 3.2 Gen 1. Processor manufacturer: Intel, Processor socket: LGA 1700, Compatible processor series: Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9,.... Supported memory types: DDR5-SDRAM, Maximum internal memory: 96 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA, Supported storage drive types: HDD & SSD. Graphics card family: Intel, Graphics card: HD Graphics, Maximum resolution: 4096 x 2304 pixels. Ethernet interface type: Gigabit Ethernet
    Supported DIMM module capacities 16GB/8GB
    Supported memory clock speed (max) 5600
    Supported memory clock speeds 4400/4800/5200/5600
    Supported memory module capacities 12GB/1GB/2GB/32GB/48GB/4GB/8GB
    Supported memory types DDR5-SDRAM
    Supported processor sockets LGA 1700
    Supported storage drive interfaces M.2,SATA
    Supported storage drive types HDD & SSD
    System Management BIOS (SMBIOS) version 2.7
    thumbnailImagePath https://static.elko.cloud/ProductImagesThumbs/369ac597-61dd-47d4-b4fe-bbb337e77806.Jpeg
    TPM connector Yes
    Unbuffered memory Yes
    Unit Calculated Volume 0.004113
    Unit Calculated Weight 0.787
    Units per Shipping Box 10
    USB 2.0 connectors 2
    USB 2.0 ports quantity 4
    USB 3.2 Gen 1 (3.1 Gen 1) connectors 1
    USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2
    Vendor Homepage https://www.gigabyte.com
    VGA (D-Sub) ports quantity 1
    Warranty period 3
    Width 230
    Windows operating systems supported Windows 10 x64/Windows 11 x64
