CASE PSU ATX 500W/TPS-500S CHIEFTEC

CASE PSU ATX 500W/TPS-500S CHIEFTEC
CASE PSU ATX 500W/TPS-500S CHIEFTEC
  • Total power: 500
  • 80 PLUS certification: 80 PLUS Bronze
  • Power supply unit (PSU) form factor: ATX
  • Fan diameter: 120
  • Number of fans: 1
3,465ден.
  • Достапност: Нема на залиха
  • Шифра: 404110
  • Гарантен рок: 12 months
  • Рок на испорака: 27.02
Сподели

Technical Specifications

  • Description:

    The CHIEFTEC Task Series PSU’s are true to their name, and take on any task they are required for without any trouble.

    With certified 80PLUS Bronze efficiency and all modern protection and safety features, the PSU can be trusted to deliver power efficiently and reliably. With cable lengths extended to 650mm for motherboard and CPU, these power supplies will also serve excellently for builds inside larger cases.

    • 80PLUS Bronze certified efficiency
    • 650mm long cables for maximum case compatibility
    • All modern protection and safety features included

  • Summary: Chieftec Task TPS-500S. Total power: 500 W, AC input voltage: 115 - 230 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 24-pin ATX, Cabling type: Non-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Compliance certificates: RoHS, Certification: ErP, RoHS, CE, CB, EAC, TÜV
  • Vendor Homepage: https://www.chieftec.eu/products-detail/180/TASK_SERIES/246/TPS-500S
  • Name: CASE PSU ATX 500W/TPS-500S CHIEFTEC
  • Category Code: PSU
  • Total power: 500
  • AC input voltage: 115 - 230
  • AC input frequency: 47 - 63
  • Power Factor Correction (PFC) type: Active
  • Combined power (+3.3V): 110
  • Combined power (+5V): 110
  • Max output current (+3.3V): 18
  • Max output current (+12V1): 38
  • Max output current (+5V): 17
  • Max output current (+5Vsb): 2.5
  • Efficiency: 85
  • Power protection features: Over power/Over voltage/Overload/Short circuit
  • Motherboard power connector: 24-pin ATX
  • Number of SATA power connectors: 5
  • Peripheral (Molex) power connectors (4-pin): 3
  • EPS power connector (4+4 pin): Yes
  • PCI Express power connectors (6+2 pin): 2
  • Cabling type: Non-Modular
  • 80 PLUS certification: 80 PLUS Bronze
  • Purpose: PC
  • Power supply unit (PSU) form factor: ATX
  • ATX version: 2.3
  • Product colour: Black
  • Cooling type: Active
  • Fan diameter: 120
  • Number of fans: 1
  • Fan location: Side
  • On/off switch: Yes
  • Compliance certificates: RoHS
  • Certification: ErP, RoHS, CE, CB, EAC, TÜV
  • Width: 150
  • Depth: 140
  • Height: 86
  • Harmonized System (HS) code: 84733020
  • Model name: TPS-500S
  • Units per Shipping Box: 1
  • Unit Calculated Volume: 0.004662
  • Unit Calculated Weight: 2
