CASE PSU ATX 600W/BBS-600S CHIEFTEC

CASE PSU ATX 600W/BBS-600S CHIEFTEC
Нема на залиха
CASE PSU ATX 600W/BBS-600S CHIEFTEC
  • Total power: 600
  • 80 PLUS certification: 80 PLUS Gold
  • Power supply unit (PSU) form factor: PS/2
  • Fan diameter: 120
  • Number of fans: 1
    • Врз основа на 0 коментари. - Напиши коментар
    5,459ден.
    • Достапност: Нема на залиха
    • Бренд: CHIEFTEC
    • Шифра: 404105
    • Гарантен рок: 12 месеци
    • Достава: 13-16 дена
    Во кошничка
    Листа на желби Спореди
    1

    Technical Specifications

    • Summary: Chieftec Core BBS-600S. Total power: 600 W, AC input voltage: 100 - 240 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 24-pin ATX, Motherboard power cable length: 65 cm, SATA power cable length: 150,500 mm. Purpose: PC, Power supply unit (PSU) form factor: PS/2, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Width: 140 mm, Depth: 150 mm, Height: 86 mm
    • Vendor Homepage: https://www.chieftec.eu/products-detail/113/CORE_SERIES/115/BBS-600S
    • Name: CASE PSU ATX 600W/BBS-600S CHIEFTEC
    • Category Code: PSU
    • Total power: 600
    • AC input voltage: 100 - 240
    • AC input frequency: 47 - 63
    • Input current: 9
    • Power Factor Correction (PFC) type: Active
    • Combined power (-12V): 3.6
    • Combined power (+5Vsb): 12.5
    • Max output current (+3.3V): 20
    • Max output current (+12V1): 49
    • Max output current (+5V): 20
    • Max output current (-12V): 0.3
    • Max output current (+5Vsb): 2.5
    • Power protection features: Over voltage/Overload/Short circuit
    • Motherboard power connector: 24-pin ATX
    • Motherboard power cable length: 650
    • Number of SATA power connectors: 6
    • SATA power cable length: 150/500
    • Peripheral (Molex) power connectors (4-pin): 3
    • Peripheral (Molex) power cable length: 150/500
    • PCI Express power connectors (6+2 pin): 2
    • PCI Express power cable length: 500
    • CPU power connector (4+4 pin): Yes
    • CPU power cable length: 650
    • Floppy drive power connector: 1
    • Cabling type: Non-Modular
    • 80 PLUS certification: 80 PLUS Gold
    • Purpose: PC
    • Power supply unit (PSU) form factor: PS/2
    • Product colour: Black
    • Cooling type: Active
    • Fan diameter: 120
    • Number of fans: 1
    • Width: 140
    • Depth: 150
    • Height: 86
    • Weight: 1670
    • Package weight: 2080
    • Harmonized System (HS) code: 84733020
    • Model name: Core 600W
    • Units per Shipping Box: 1
    • Unit Calculated Volume: 0.004662
    • Unit Calculated Weight: 2.47
    Specs
    80 PLUS certification 80 PLUS Gold
    AC input frequency 47 - 63
    AC input voltage 100 - 240
    Cabling type Non-Modular
    Category Code PSU
    Combined power (+5Vsb) 12.5
    Combined power (-12V) 3.6
    Cooling type Active
    CPU power cable length 650
    CPU power connector (4+4 pin) Yes
    Depth 150
    Description

    With the Core Series, Chieftec will be bringing a new 80 PLUS Gold certified PSU to market, offering the best possible value-formoney. The goal of the Core Series power-supplies is to deliver a no-nonsense package of performance, efficiency and reliability. With power output ranging from 500W to 700W, this product is idea for customers who want top-tier power output at the most attractive price.

    • 80 PLUS Gold Efficiency
    • Compact size with only 140mm depth
    • Motherboard, CPU and PCI-E cable lengths of 650mm
    Fan diameter 120
    Floppy drive power connector 1
    Harmonized System (HS) code 84733020
    Height 86
    Input current 9
    Max output current (+12V1) 49
    Max output current (+3.3V) 20
    Max output current (+5V) 20
    Max output current (+5Vsb) 2.5
    Max output current (-12V) 0.3
    Model name Core 600W
    Motherboard power cable length 650
    Motherboard power connector 24-pin ATX
    Name CASE PSU ATX 600W/BBS-600S CHIEFTEC
    Number of fans 1
    Number of SATA power connectors 6
    Package weight 2080
    PCI Express power cable length 500
    PCI Express power connectors (6+2 pin) 2
    Peripheral (Molex) power cable length 150/500
    Peripheral (Molex) power connectors (4-pin) 3
    PictureUrl https://static.elko.cloud/ProductImages/29ab775d-0db1-407a-9589-1e5c9e6a2064.Jpeg
    Power Factor Correction (PFC) type Active
    Power protection features Over voltage/Overload/Short circuit
    Power supply unit (PSU) form factor PS/2
    Product colour Black
    Purpose PC
    SATA power cable length 150/500
    Summary Chieftec Core BBS-600S. Total power: 600 W, AC input voltage: 100 - 240 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 24-pin ATX, Motherboard power cable length: 65 cm, SATA power cable length: 150,500 mm. Purpose: PC, Power supply unit (PSU) form factor: PS/2, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Width: 140 mm, Depth: 150 mm, Height: 86 mm
    thumbnailImagePath https://static.elko.cloud/ProductImagesThumbs/29ab775d-0db1-407a-9589-1e5c9e6a2064.Jpeg
    Total power 600
    Unit Calculated Volume 0.004662
    Unit Calculated Weight 2.47
    Units per Shipping Box 1
    Vendor Homepage https://www.chieftec.eu/products-detail/113/CORE_SERIES/115/BBS-600S
    Weight 1670
    Width 140
