CASE PSU ATX 750W SYNERGY 750/PSAT1075A20CSCZ01B NJOY

CASE PSU ATX 750W SYNERGY 750/PSAT1075A20CSCZ01B NJOY
Нема на залиха
CASE PSU ATX 750W SYNERGY 750/PSAT1075A20CSCZ01B NJOY
  • Total power: 750
  • 80 PLUS certification: 80 PLUS White
  • Power supply unit (PSU) form factor: ATX
  • Fan diameter: 120
  • Number of fans: 1
    • Врз основа на 0 коментари. - Напиши коментар
    3,335ден.
    • Достапност: Нема на залиха
    • Бренд: NJOY
    • Шифра: 426331
    • Гарантен рок: 12 месеци
    • Достава: 13-16 дена
    Во кошничка
    Листа на желби Спореди
    1

    Technical Specifications

    • Summary: nJoy Synergy 750. Total power: 750 W, AC input voltage: 230 V, AC input frequency: 50 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 50 cm, SATA power cable length: 150,450 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS White. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Certification: CE, RoHS
    • Vendor Homepage: https://www.njoy.global/product/synergy-750/PSAT1075A20CSCZ01B
    • Name: CASE PSU ATX 750W SYNERGY 750/PSAT1075A20CSCZ01B NJOY
    • Category Code: PSU
    • Total power: 750
    • AC input voltage: 230
    • AC input frequency: 50
    • Power Factor Correction (PFC) type: Active
    • Combined power (+3.3V): 120
    • Combined power (+12V): 696
    • Combined power (+5V): 120
    • Combined power (-12V): 6
    • Combined power (+5Vsb): 12.5
    • Max output current (+3.3V): 24
    • Max output current (+12V): 58
    • Max output current (+5V): 18
    • Max output current (-12V): 0.5
    • Max output current (+5Vsb): 2.5
    • Efficiency: 82
    • Power protection features: Over power/Over voltage/Short circuit/Under voltage
    • Motherboard power connector: 20+4 pin ATX
    • Motherboard power cable length: 500
    • Number of SATA power connectors: 5
    • SATA power cable length: 150/450
    • Peripheral (Molex) power connectors (4-pin): 3
    • Peripheral (Molex) power cable length: 150/450
    • PCI Express power connectors (6+2 pin): 2
    • CPU power connector (4+4 pin): Yes
    • CPU power cable length: 600
    • Number of EPS connectors: 2
    • Cabling type: Non-Modular
    • 80 PLUS certification: 80 PLUS White
    • Purpose: PC
    • Power supply unit (PSU) form factor: ATX
    • ATX version: 2.31
    • Bearing technology: Hydraulic
    • Product colour: Black
    • Cooling type: Active
    • Fan diameter: 120
    • Number of fans: 1
    • Fan location: Top
    • Certification: CE, RoHS
    • Width: 145
    • Depth: 150
    • Height: 86
    • Weight: 1590
    • Master (outer) case width: 533
    • Master (outer) case length: 538
    • Master (outer) case height: 195
    • Master (outer) case gross weight: 17560
    • Master (outer) case net weight: 16700
    • Products per master (outer) case: 10
    • Units per Pallet: 0
    • Units per Shipping Box: 1
    • Unit Calculated Volume: 0.002835
    • Unit Calculated Weight: 1.756
    Specs
    80 PLUS certification 80 PLUS White
    AC input frequency 50
    AC input voltage 230
    ATX version 2.31
    Bearing technology Hydraulic
    Cabling type Non-Modular
    Category Code PSU
    Certification CE, RoHS
    Combined power (+12V) 696
    Combined power (+3.3V) 120
    Combined power (+5V) 120
    Combined power (+5Vsb) 12.5
    Combined power (-12V) 6
    Cooling type Active
    CPU power cable length 600
    CPU power connector (4+4 pin) Yes
    Depth 150
    Description

    SYNERGY SERIES
    IN SYNERGY WITH POWER
    Synergy Series is our line designed for system integration in PC structures that provides reliability and high-quality components for a substantial cost-effective product. With the updated design and features Synergy meets every test for the 80+ White 230V EU standard, having features as DC-to-DC, PFC Active, Hydraulic Bearing Fan, Flat Cables for a better management in the case, this will establish that the power supplies are built with a higher standard in mind.

    Efficiency at 80+ 230V EU White tier
    Synergy meets the 80+ White 230V EU standard, and ensures efficiency of 82%, 85%, and 82% with performance at 20%, 50%, and 100% loads. This testing establishes that these power supplies are built for better stability and support for IT projects.

    DC-to-DC Technology
    By using DC-DC converters, the PSU can deliver various output voltages with high efficiency and accuracy. With DC-to-DC technology, the +3.3V and +5V outputs can be easily obtained for maximum stability.

    Hydraulic bearing fan
    Hydraulic bearings use a thin layer of oil to create a lubricated film between the rotating shaft and the bearing. This design reduces friction, which results in quieter operation and longer lifespan compared to traditional sleeve bearings.

    Optimal Shielding
    Nothing can go wrong when the power supply is decked with protection systems that will save your most valued components from unfortunate events. Synergy provides OVP / UVP / SCP / OPP in accordance with international standards.

    Flat cords connecting to power
    Synergy series comes equipped with black, flattened long cables that will make for improved wire management and the chassis interior will remain clutter-free for a superior level of ventilation.

    • Meets 80+ White 230V EU Standard
    • DC to DC Technology
    • Active PFC
    Efficiency 82
    Fan diameter 120
    Fan location Top
    Height 86
    Master (outer) case gross weight 17560
    Master (outer) case height 195
    Master (outer) case length 538
    Master (outer) case net weight 16700
    Master (outer) case width 533
    Max output current (+12V) 58
    Max output current (+3.3V) 24
    Max output current (+5V) 18
    Max output current (+5Vsb) 2.5
    Max output current (-12V) 0.5
    Motherboard power cable length 500
    Motherboard power connector 20+4 pin ATX
    Name CASE PSU ATX 750W SYNERGY 750/PSAT1075A20CSCZ01B NJOY
    Number of EPS connectors 2
    Number of fans 1
    Number of SATA power connectors 5
    PCI Express power connectors (6+2 pin) 2
    Peripheral (Molex) power cable length 150/450
    Peripheral (Molex) power connectors (4-pin) 3
    PictureUrl https://static.elko.cloud/ProductImages/64a614d3-b1ff-4455-be87-0b181e6f4c0e.Jpeg
    Power Factor Correction (PFC) type Active
    Power protection features Over power/Over voltage/Short circuit/Under voltage
    Power supply unit (PSU) form factor ATX
    Product colour Black
    Products per master (outer) case 10
    Purpose PC
    SATA power cable length 150/450
    Summary nJoy Synergy 750. Total power: 750 W, AC input voltage: 230 V, AC input frequency: 50 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 50 cm, SATA power cable length: 150,450 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS White. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Certification: CE, RoHS
    thumbnailImagePath https://static.elko.cloud/ProductImagesThumbs/64a614d3-b1ff-4455-be87-0b181e6f4c0e.Jpeg
    Total power 750
    Unit Calculated Volume 0.002835
    Unit Calculated Weight 1.756
    Units per Pallet 0
    Units per Shipping Box 1
    Vendor Homepage https://www.njoy.global/product/synergy-750/PSAT1075A20CSCZ01B
    Weight 1590
    Width 145
