- Достапност: Нема на залиха
- Бренд: INTEL
- Шифра: 137653
- Гарантен рок: 12 месеци
- Достава: 13-16 дена
Technical Specifications
- Summary: Intel Core i3-3120M. Processor family: Intel Core i3, Processor socket: PGA988, Processor lithography: 22 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 32 GB, Memory types supported by processor: DDR3-SDRAM, DDR3L-SDRAM, DDR3L-RS-SDRAM. On-board graphics card model: Intel HD Graphics 4000, On-board graphics card outputs supported: Embedded DisplayPort (eDP), DisplayPort, HDMI, Serial Digital Video Out (SDVO), CRT, On-board graphics card base frequency: 650 MHz. Market segment: Mobile, PCI Express configurations: 1x16, 2x8, 1x8, 2x4, Supported instruction sets: AVX. Processor package size: 37.5mm x 37.5mm; 31mm x 24mm
- Vendor Homepage: https://ark.intel.com/products/71465/
- Name: CPU CORE I3-3120M S988 OEM 3M/2.5G AW8063801111700S R0TX IN
- Category Code: CPU
- Processor manufacturer: Intel
- Processor generation: 3rd gen Intel Core i3
- Processor model: i3-3120M
- Processor base frequency: 2.5
- Processor family: Intel Core i3
- Processor cores: 2
- Processor socket: PGA988
- Component for: Laptop
- Processor lithography: 22
- Processor series: Intel Core i3-3100 Mobile Series
- Processor threads: 4
- System bus rate: 5
- Processor operating modes: 64-bit
- Processor cache: 3
- Processor cache type: Smart Cache
- Thermal Design Power (TDP): 35
- Package type: Tray
- Generation: 3rd Generation
- Bus type: DMI
- CPU multiplier (bus/core ratio): 25
- Memory bandwidth supported by processor (max): 25.6
- Processor codename: Ivy Bridge
- Processor ARK ID: 71465
- Maximum internal memory supported by processor: 32
- Memory types supported by processor: DDR3L-RS-SDRAM/DDR3L-SDRAM/DDR3-SDRAM
- Memory clock speeds supported by processor: 1333/1600
- Memory channels: Dual-channel
- On-board graphics card: Yes
- On-board graphics card model: Intel HD Graphics 4000
- On-board graphics card outputs supported: CRT/DisplayPort/Embedded DisplayPort (eDP)/HDMI/Serial Digital Video Out (SDVO)
- On-board graphics card base frequency: 650
- On-board graphics card dynamic frequency (max): 1100
- Number of displays supported (on-board graphics): 3
- On-board graphics card ID: 0x166
- Execute Disable Bit: Yes
- Idle States: Yes
- Thermal Monitoring Technologies: Yes
- Integrated 4G WiMAX: Yes
- Market segment: Mobile
- Maximum number of PCI Express lanes: 16
- PCI Express slots version: 2.0
- PCI Express configurations: 1x16/1x8/2x4/2x8
- Supported instruction sets: AVX
- Bandwidth: 5
- CPU configuration (max): 1
- Graphics & IMC lithography: 22
- PCI Express CEM revision: 2.0
- Export Control Classification Number (ECCN): 3A991
- Commodity Classification Automated Tracking System (CCATS): NA
- Enhanced Intel SpeedStep Technology: Yes
- Intel Dual Display Capable Technology: Yes
- Intel Fast Memory Access: Yes
- Intel FDI Technology: Yes
- Intel Flex Memory Access: Yes
- Intel Anti-Theft Technology (Intel AT): Yes
- Intel Clear Video HD Technology (Intel CVT HD): Yes
- Intel Hyper Threading Technology (Intel HT Technology): Yes
- Intel Identity Protection Technology (Intel IPT): Yes
- Intel Insider: Yes
- Intel InTru 3D Technology: Yes
- Intel My WiFi Technology (Intel MWT): Yes
- Intel Quick Sync Video Technology: Yes
- Intel Smart Cache: Yes
- Intel Wireless Display (Intel WiDi): Yes
- Conflict-Free processor: Yes
- Intel 64: Yes
- Intel Enhanced Halt State: Yes
- Intel Identity Protection Technology version: 1.00
- Intel Virtualization Technology (VT-x): Yes
- Intel VT-x with Extended Page Tables (EPT): Yes
- Intel Clear Video Technology for Mobile Internet Devices (Intel CVT for MID): Yes
- Tjunction: 105
- Born on date: Q312
- Bus bandwidth: 5
- Bus speed: 5 GT/s
- Bus type units: GT/s
- Graphics max dynamic frequency: 1.10 GHz
- Last change: 63903513
- Launch date: Q312
- Maximum memory: 32
- Processor brand name: Intel Core i3 Intel Core i3 Processor
- Processor cache: 3072
- Processor ID: 0x166
- Product family: 3rd Generation Intel Core i3 Processors
- Product name: Intel Core i3-3120M (3M Cache, 2.50 GHz)
- Product type: Processor
- Status: Discontinued
- Supported memory types: DDR3L-RS-SDRAM/DDR3L-SDRAM/DDR3-SDRAM
- Harmonized System (HS) code: 8542310001
- Processor package size: 37.5mm x 37.5mm; 31mm x 24mm
- Intel Virtualization Technology (Intel VT): VT-d/VT-x
- Cache memory: 3
- Graphics output: eDP/DP/HDMI/SDVO/CRT
- Maximum internal memory: 32
- Maximum internal memory: 32768
- CPU Family name: Intel Core i3
- Unit Calculated Volume: 7E-05
- Unit Calculated Weight: 0.04
| Specifications | |
| Bandwidth | 5 |
| Born on date | Q3'12 |
| Bus bandwidth | 5 |
| Bus speed | 5 GT/s |
| Bus type | DMI |
| Bus type units | GT/s |
| Cache memory | 3 |
| Conflict-Free processor | Yes |
| CPU configuration (max) | 1 |
| CPU multiplier (bus/core ratio) | 25 |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Generation | 3rd Generation |
| Graphics & IMC lithography | 22 |
| Graphics max dynamic frequency | 1.10 GHz |
| Graphics output | eDP/DP/HDMI/SDVO/CRT |
| Idle States | Yes |
| Integrated 4G WiMAX | Yes |
| Intel 64 | Yes |
| Intel Dual Display Capable Technology | Yes |
| Intel Enhanced Halt State | Yes |
| Intel Fast Memory Access | Yes |
| Intel FDI Technology | Yes |
| Intel Flex Memory Access | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Anti-Theft Technology (Intel® AT) | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Inte | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® My WiFi Technology (Intel® MWT) | Yes |
| Intel® Smart Cache | Yes |
| Intel® Wireless Display (Intel® WiDi) | Yes |
| Last change | 63903513 |
| Maximum memory | 32 |
| Maximum number of PCI Express lanes | 16 |
| Memory bandwidth supported by processor (max) | 25.6 |
| Memory clock speeds supported by processor | 1333/1600 |
| Memory types supported by processor | DDR3L-RS-SDRAM/DDR3L-SDRAM/DDR3-SDRAM |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics card base frequency | 650 |
| On-board graphics card dynamic frequency (max) | 1100 |
| On-board graphics card ID | 0x166 |
| On-board graphics card outputs supported | CRT/DisplayPort/Embedded DisplayPort (eDP)/HDMI/Serial Digital Video Out (SDVO) |
| Processor ARK ID | 71465 |
| Processor base frequency | 2.5 |
| Processor brand name | Intel Core i3 Intel Core i3 Processor |
| Processor cache | 3072 |
| Processor cache type | Smart Cache |
| Processor codename | Ivy Bridge |
| Processor generation | 3rd gen Intel® Core™ i3 |
| Processor ID | 0x166 |
| Processor operating modes | 64-bit |
| Processor package size | 37.5mm x 37.5mm; 31mm x 24mm |
| Processor series | Intel Core i3-3100 Mobile Series |
| Processor threads | 4 |
| Product family | 3rd Generation Intel Core i3 Processors |
| Product name | Intel Core i3-3120M (3M Cache, 2.50 GHz) |
| Supported instruction sets | AVX |
| Thermal Monitoring Technologies | Yes |
| Tjunction | 105 |
| Specs | |
| Category Code | CPU |
| Commodity Classification Automated Tracking System (CCATS) | NA |
| Component for | Laptop |
| CPU Family name | Intel Core i3 |
| Description | Intel® Quick Sync Video |
| Export Control Classification Number (ECCN) | 3A991 |
| Harmonized System (HS) code | 8542310001 |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® Insider™ | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Virtualization Technology (Intel® VT) | VT-d/VT-x |
| Launch date | Q3'12 |
| Market segment | Mobile |
| Maximum internal memory | 32768 |
| Maximum internal memory supported by processor | 32 |
| Memory channels | Dual-channel |
| Name | CPU CORE I3-3120M S988 OEM 3M/2.5G AW8063801111700S R0TX IN |
| On-board graphics card | Yes |
| On-board graphics card model | Intel® HD Graphics 4000 |
| Package type | Tray |
| PCI Express CEM revision | 2.0 |
| PCI Express configurations | 1x16/1x8/2x4/2x8 |
| PCI Express slots version | 2.0 |
| PictureUrl | https://static.elko.cloud/ProductImages/49713d52-d224-4eed-b97d-7c5e6ecbb9ca.Jpeg |
| Processor cores | 2 |
| Processor family | Intel® Core™ i3 |
| Processor lithography | 22 |
| Processor manufacturer | Intel |
| Processor model | i3-3120M |
| Processor socket | PGA988 |
| Product type | Processor |
| Status | Discontinued |
| Summary | Intel Core i3-3120M. Processor family: Intel® Core™ i3, Processor socket: PGA988, Processor lithography: 22 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 32 GB, Memory types supported by processor: DDR3-SDRAM, DDR3L-SDRAM, DDR3L-RS-SDRAM. On-board graphics card model: Intel® HD Graphics 4000, On-board graphics card outputs supported: Embedded DisplayPort (eDP), DisplayPort, HDMI, Serial Digital Video Out (SDVO), CRT, On-board graphics card base frequency: 650 MHz. Market segment: Mobile, PCI Express configurations: 1x16, 2x8, 1x8, 2x4, Supported instruction sets: AVX. Processor package size: 37.5mm x 37.5mm; 31mm x 24mm |
| Supported memory types | DDR3L-RS-SDRAM/DDR3L-SDRAM/DDR3-SDRAM |
| System bus rate | 5 |
| Thermal Design Power (TDP) | 35 |
| thumbnailImagePath | https://static.elko.cloud/ProductImagesThumbs/49713d52-d224-4eed-b97d-7c5e6ecbb9ca.Jpeg |
| Unit Calculated Volume | 7E-05 |
| Unit Calculated Weight | 0.04 |
| Vendor Homepage | https://ark.intel.com/products/71465/ |
