Intel Core i5 i5-12600KF

Technical Specifications

• Summary: Intel Core i5-12600KF. Processor family: Intel Core i5, Processor socket: LGA 1700, Package type: Box. Memory channels: Dual-channel, Maximum internal memory supported by processor: 128 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. Market segment: Desktop, Use conditions: PC/Client/Tablet, PCI Express slots version: 5.0, 4.0. Processor package size: 45 x 37.5 mm. L2 cache: 9728 KB, Maximum internal memory: 128 GB
• Vendor Homepage: https://www.intel.com/
• Name: CPU CORE I5-12600KF S1700 BOX/3.7G BX8071512600KF S RL4U IN
• Category Code: CPU
• Processor manufacturer: Intel
• Processor generation: 12th gen Intel Core i5
• Processor model: i5-12600KF
• Processor family: Intel Core i5
• Processor cores: 10
• Processor socket: LGA 1700
• Component for: PC
• Processor threads: 16
• Processor operating modes: 64-bit
• Performance cores: 6
• Efficient cores: 4
• Processor boost frequency: 4.9
• Performance-core boost frequency: 4.9
• Performance-core base frequency: 3.7
• Efficient-core boost frequency: 3.6
• Efficient-core base frequency: 2.8
• Processor cache: 20
• Processor cache type: Smart Cache
• Package type: Box
• Maximum turbo power: 150
• Processor base power: 125
• Bus type: DMI4
• Maximum number of DMI lanes: 8
• Memory bandwidth supported by processor (max): 76.8
• Processor codename: Alder Lake
• Processor ARK ID: 134590
• Maximum internal memory supported by processor: 128
• Memory types supported by processor: DDR4-SDRAM/DDR5-SDRAM
• Memory channels: Dual-channel
• Non-ECC: Yes
• Memory bandwidth (max): 76.8
• Execute Disable Bit: Yes
• Idle States: Yes
• Thermal Monitoring Technologies: Yes
• Market segment: Desktop
• Use conditions: PC/Client/Tablet
• Maximum number of PCI Express lanes: 20
• PCI Express slots version: 4.0/5.0
• PCI Express configurations: 1x16+1x4/2x8+1x4
• Supported instruction sets: AVX 2.0/SSE4.1/SSE4.2
• CPU configuration (max): 1
• Direct Media Interface (DMI) Revision: 4.0
• Scalability: 1S
• Thermal solution specification: PCG 2020A
• Export Control Classification Number (ECCN): 5A992.C
• Commodity Classification Automated Tracking System (CCATS): G167599
• Enhanced Intel SpeedStep Technology: Yes
• Intel AES New Instructions (Intel AES-NI): Yes
• Intel Hyper Threading Technology (Intel HT Technology): Yes
• Intel Speed Shift Technology: Yes
• Intel Turbo Boost Technology: 2.0
• Intel Gaussian & Neural Accelerator (Intel GNA) 3.0: Yes
• Intel Control-flow Enforcement Technology (CET): Yes
• Intel Thread Director: Yes
• Intel 64: Yes
• Intel Enhanced Halt State: Yes
• Intel Virtualization Technology (VT-x): Yes
• Intel Virtualization Technology for Directed I/O (VT-d): Yes
• Intel VT-x with Extended Page Tables (EPT): Yes
• Intel Boot Guard: Yes
• Intel Deep Learning Boost (Intel DL Boost) on CPU: Yes
• Intel Optane Memory Ready: Yes
• Intel OS Guard: Yes
• Intel Secure Key: Yes
• Intel Standard Manageability (ISM): Yes
• Intel Volume Management Device (VMD): Yes
• Mode-based Execute Control (MBE): Yes
• Maximum operating temperature: 100
• Tjunction: 100
• Target market: Gaming
• Launch date: Q421
• Status: Launched
• Harmonized System (HS) code: 85423119
• Processor package size: 45 x 37.5
• L2 cache: 9728
• Maximum internal memory: 128
• CPU Family name: Intel Core i5
• Model number: i5-12600KF
• Units per Pallet: 0
• Units per Shipping Box: 5
• Unit Calculated Volume: 0.00072
• Unit Calculated Weight: 0.108
