MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS

MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
MB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
  • Motherboard chipset: AMD B550
  • Motherboard form factor: ATX
  • Processor socket: Socket AM4
  • Supported memory types: DDR4-SDRAM
  • Number of memory slots: 4
    • Врз основа на 0 коментари. - Напиши коментар
    12,840ден.
    • Достапност:
    • Бренд: ASUS
    • Шифра: 322006
    • Гарантен рок: 36 месеци
    • Достава: 13-16 дена
    Во кошничка
    Листа на желби Спореди
    1
    Specifications
    ECC сompatibilityECC
    Specs
    ATX Power connector (24-pin)Yes
    Audio chipRealtek ALC S1200A
    Audio connectorYes
    Audio output channels7.1
    BIOS memory size256
    BIOS typeUEFI AMI
    Cables includedSATA
    Category CodeMBA
    Clear CMOS jumperYes
    Compatible processor seriesAMD Ryzen 3000 Series
    Component forPC
    CPU fan connectorYes
    Depth244
    DisplayPort version1.2
    DisplayPorts quantity1
    Drivers includedYes
    Ethernet interface type2.5 Gigabit Ethernet
    Ethernet LANYes
    Ethernet LAN (RJ-45) ports1
    Front panel audio connectorYes
    Front panel connectorYes
    Harmonized System (HS) code84733020
    HDMI ports quantity1
    HDMI version2.1
    Headphone outputs1
    LAN controllerRealtek RTL8125B
    Maximum internal memory128
    Maximum number of SMP processors1
    Memory channelsDual-channel
    Memory slots typeDIMM
    Microphone inYes
    Motherboard chipsetAMD B550
    Motherboard chipset familyAMD
    Motherboard form factorATX
    NameMB AMD B550 SAM4 ATX/TUF GAM B550-PLUS (WI-FI) ASUS
    Number of chassis fan connectors1
    Number of COM connectors1
    Number of displays supported2
    Number of M.2 (M) slots2
    Number of memory slots4
    Number of mounting holes9
    Number of SATA III connectors6
    Parallel processing technology support2-Way CrossFireX
    PCI Express x1 (Gen 3.x) slots3
    PCI Express x16 (Gen 3.x) slots1
    PCI Express x16 (Gen 4.x) slots1
    Processor manufacturerAMD
    Processor socketSocket AM4
    Product Net Weight1.3
    Product typeOffice
    RAID levels0/1/10/5
    S/PDIF out portYes
    Shipping Box Depth36.2
    Shipping Box Height29.3
    Shipping Box Weight8.68
    Shipping Box Width35.9
    SummaryASUS TUF GAMING B550-PLUS (WI-FI). Processor manufacturer: AMD, Processor socket: Socket AM4, Compatible processor series: AMD Ryzen 3000 Series. Supported memory types: DDR4-SDRAM, Maximum internal memory: 128 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. Parallel processing technology support: 2-Way CrossFireX. USB connector type: USB Type-A, USB Type-C
    Supported memory clock speeds2133/2400/2666/2800/3000/3200/3333/3466/3600/3733/3866/4000/4133/4266/4400/4466/4600/4800
    Supported memory typesDDR4-SDRAM
    Supported storage drive interfacesM.2,SATA
    Supported storage drive typesHDD & SSD
    Thunderbolt headers1
    Top Wi-Fi standardWi-Fi 5 (802.11ac)
    TPM connectorYes
    Unit Calculated Volume0.007616
    Unit Calculated Weight1.74
    Units per Shipping Box5
    USB 2.0 connectors2
    USB 2.0 ports quantity2
    USB 3.2 Gen 1 (3.1 Gen 1) connectors1
    USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
    USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity1
    USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
    USB connector typeUSB Type-A/USB Type-C
    Vendor Homepagehttps://www.asus.com/Motherboards/TUF-GAMING-B550-PLUS-WI-FI/overview/
    Wi-FiYes
    Wi-Fi standards802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)
    Width305
    Windows operating systems supportedWindows 10 x64
