MB H470 S1200 MATX/H510M-HDV/M.2 SE ASROCK

MB H470 S1200 MATX/H510M-HDV/M.2 SE ASROCK
MB H470 S1200 MATX/H510M-HDV/M.2 SE ASROCK
MB H470 S1200 MATX/H510M-HDV/M.2 SE ASROCK
MB H470 S1200 MATX/H510M-HDV/M.2 SE ASROCK
MB H470 S1200 MATX/H510M-HDV/M.2 SE ASROCK
MB H470 S1200 MATX/H510M-HDV/M.2 SE ASROCK
MB H470 S1200 MATX/H510M-HDV/M.2 SE ASROCK
MB H470 S1200 MATX/H510M-HDV/M.2 SE ASROCK
MB H470 S1200 MATX/H510M-HDV/M.2 SE ASROCK
MB H470 S1200 MATX/H510M-HDV/M.2 SE ASROCK
MB H470 S1200 MATX/H510M-HDV/M.2 SE ASROCK
  • Motherboard chipset: Intel H470
  • Motherboard form factor: micro ATX
  • Processor socket: LGA 1200 (Socket H5)
  • Supported memory types: DDR4-SDRAM
  • Number of memory slots: 2
  • Number of storage drives supported: 5
    • Врз основа на 0 коментари. - Напиши коментар
    4,414ден.
    • Достапност:
    • Бренд: ASROCK
    • Шифра: 398245
    • Гарантен рок: 24 месеци
    • Достава: 13-16 дена
    Во кошничка
    Листа на желби Спореди
    1
    Specifications
    ECC сompatibilityNon-ECC
    Unit Depth28
    Unit Height24
    Unit Width6
    Specs
    12V power connectorYes
    ATX Power connector (24-pin)Yes
    Audio chipRealtek ALC897
    Audio output channels7.1
    BIOS memory size128
    BIOS typeUEFI AMI
    Cables includedSATA
    Category CodeMBI
    Chassis intrusion connectorYes
    COM ports quantity1
    Compliance certificatesCE/EuP/Federal Communications Commission (FCC)
    Component forPC
    CPU fan connectorYes
    Depth198
    DVI-D ports quantity1
    Ethernet interface typeGigabit Ethernet
    Ethernet LANYes
    Ethernet LAN (RJ-45) ports1
    Front panel audio connectorYes
    HDCPYes
    HDMI ports quantity1
    HDMI version1.4/2.0
    Headphone outputs1
    LAN controllerRealtek 8111H
    Line-inYes
    Maximum internal memory64
    Memory channelsDual-channel
    Memory slots typeDIMM
    Microphone inYes
    ModelH510M-HDV/M.2 SE
    Motherboard chipsetIntel H470
    Motherboard form factormicro ATX
    NameMB H470 S1200 MATX/H510M-HDV/M.2 SE ASROCK
    Number of chassis fan connectors2
    Number of displays supported3
    Number of HDDs supported4
    Number of M.2 (M) slots1
    Number of memory slots2
    Number of SATA III connectors4
    Number of storage drives supported5
    PCI Express x1 (Gen 3.x) slots1
    PCI Express x16 (Gen 4.x) slots1
    Processor manufacturerIntel
    Processor socketLGA 1200 (Socket H5)
    Product Net Weight0.7
    Product typeOffice
    PS/2 ports quantity1
    RAID levels0/1/10/5
    RAID supportYes
    Shipping Box Depth60.7000007629395
    Shipping Box Height49.7000007629395
    Shipping Box Weight16.0200004577637
    Shipping Box Width28.5
    SummaryAsrock H510M-HDV/M.2 SE. Processor manufacturer: Intel, Processor socket: LGA 1200 (Socket H5). Supported memory types: DDR4-SDRAM, Maximum internal memory: 64 GB, Memory slots type: DIMM. Supported storage drive interfaces: PCI Express 3.0, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. HDMI version: 1.4/2.0, USB connector type: USB Type-A. Ethernet interface type: Gigabit Ethernet, LAN controller: Realtek 8111H
    Supported memory clock speed (max)3200
    Supported memory clock speeds2133/2400/2666/2800/2933/3200
    Supported memory typesDDR4-SDRAM
    Supported storage drive interfacesPCI Express 3.0,SATA III
    Supported storage drive typesHDD & SSD
    Sustainability certificatesErP
    Sustainability complianceYes
    TPM connectorYes
    Unbuffered memoryYes
    Unit Calculated Volume0.004299
    Unit Calculated Weight0.801
    Units per Pallet0
    Units per Shipping Box20
    USB 2.0 connectors2
    USB 2.0 ports quantity2
    USB 3.2 Gen 1 (3.1 Gen 1) connectors1
    USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
    USB connector typeUSB Type-A
    Vendor Homepagehttps://www.asrock.com/MB/Intel/H510M-HDVM.2%20SE/index.asp
    VGA (D-Sub) ports quantity1
    Width231
    Windows operating systems supportedWindows 10 x64/Windows 11 x64
